| ブランド名: | GENY |
| モデル番号: | YC-1891D |
| MOQ: | 1個のPC |
| 価格: | 交渉可能 |
| 支払条件: | L/C、T/T、D/P |
| 供給能力: | 100/年 |
| Voltage | 3×230/398V±10% |
| Frequency | 50/60Hz±2Hz |
| Power capacity | > 6kVA |
| Ambient temperature | -10°C -- +40°C |
| Relative humidity | 35% -- 85% |
| Test voltage output (Phase-Neutral) | 24V - 300V |
| Power of the voltage output | 1000VA |
| Resolution | Better than 0.01% of full scale value of range |
| Setting accuracy | Better than 0.05% at the final range value |
| Stability | Better than 0.005%/h (integration time 150 s) |
| Load regulation from 0-max. load | < 0.01% |
| Distortion factor | < 0.3% for linear resistance load |
| Harmonics | 2nd - 21st free programmable |
| Test current output | 1mA - 120A |
| Power of the current output | 1500VA |
| Resolution | Better than 0.01% of full scale value of range |
| Setting accuracy | Better than 0.05% at the final range value |
| Stability | Better than 0.005%/h (integration time 150 s) |
| Load regulation from 0-max. load | < 0.01% |
| Distortion factor | < 0.3% for linear resistance load |
| Harmonics | 2nd - 21st free programmable |
| Range | 0 -- 360° |
| Resolution | 0.01° |
| Setting accuracy | 0.1° |
| Range | 45Hz - 65Hz |
| Resolution | 0.01Hz |
| Number of secondary | 50 |
| Voltage range | 300V |
| Ratio | 1:1 |
| Primary to secondary ratio error | 0.25% |
| Secondary to secondary ratio error | 0.02% |
| Secondary to secondary Phase error | 0.02° |
| Frequency range | 45Hz - 65Hz |
| Output power (per winding) | 15VA |
