| ブランド名: | GENY |
| モデル番号: | YCRT-I370 |
| MOQ: | 1 |
| 価格: | negotiate rates |
| 支払条件: | L/C、D/A、D/P、T/T、Western Union、MoneyGram |
| 供給能力: | 30個/1ヶ月 |
| Function | Battery internal resistance measurement, battery voltage measurement, temperature measurement |
|---|---|
| Accuracy Conditions | 23℃±5℃, Below 75% RH |
| Power Supply | DC 3.7V lithium battery |
| Resolution | Resistance: 1μΩ | Voltage: 1mV | Temperature: 0.1℃ |
| Measuring Ranges |
Internal resistance: 0.000mΩ~3.100Ω (4 ranges) Voltage: 0.000V~±122.0V (2 ranges) Temperature: -10.0℃~60.0℃ |
| Measurement Method | 1KHz AC 4-terminal test method (3V max open-circuit voltage) |
| Display | 3.5-inch 16-bit true color LCD (320*240 resolution) |
| Connectivity | USB interface and Bluetooth |
| Dimensions | 190mm * 121mm * 51mm |
| Weight | 480g (including battery) |
| Safety Compliance | IEC 61010 |
