| ブランド名: | GENY |
| モデル番号: | YC1893-24 |
| MOQ: | 1個 |
| 価格: | 交渉可能 |
| 支払条件: | L/C、T/T、D/P |
| 供給能力: | 1ヶ月あたり30個 |
| Technical Specification | YC1893D-24 |
|---|---|
| Number of meter positions | 24 |
| Accuracy | 0.05 / 0.02 |
| Power Source | YCS-103-1200 |
| Standard Meter | SZ03A-K6 / SZ03A-K8 |
| Scanning Head | YCG-S Series |
| Voltage Specifications | |
| Test voltage output (Phase-Neutral) | 3x(24V~288V) (or customized) |
| Power of the voltage output | Max. 3x500VA |
| Resolution | Better than 0.01% of full scale value of range |
| Setting accuracy | Better than 0.05% at the final range value |
| Stability | Better than 0.005% /h (integration time 150s) |
| Load regulation from 0~max. load | Better than 0.01% |
| Distortion factor | Better than 0.3% for linear resistance load |
| Harmonic | 2nd~21st free programmable |
| Current Specifications | |
| Test current output | 3x(1mA~100A) |
| Power of the current output | Max. 3x750VA |
| Resolution | Better than 0.01% of full scale value of range |
| Setting accuracy | Better than 0.05% at the final range value |
| Stability | Better than 0.005% /h (integration time 150s) |
| Load regulation from 0~max. load | Better than 0.01% |
| Distortion factor | Better than 0.3% for linear resistance load |
| Harmonic | 2nd~21st free programmable |
| Phase Angle Specifications | |
| Range | 0~360⁰ |
| Resolution | 0.01⁰ |
| Setting accuracy | 0.1⁰ |
| Frequency Specifications | |
| Range | 45Hz~65Hz |
| Resolution | 0.01Hz |
| Error Display | |
| Type of error display | Red LED |
| Resolution of error displays | 8 digitals |
| Other Specifications | |
| Voltage supply | 3x220/380V±10% (or customized) 50/60Hz ±2Hz |
| Ambient temperature | -10°C~+40°C |
| Relative humidity | 35%~85% |
