| ブランド名: | GENY |
| モデル番号: | YC-1891D |
| MOQ: | 1個 |
| 価格: | 交渉可能 |
| 支払条件: | L/C、T/T、D/P |
| 供給能力: | 100/年 |
| Main Technical Indicators | Parameter Value |
|---|---|
| Power Supply | AC220V±10%, 50Hz±2Hz |
| Ambient Temperature | -10°C ... +40°C |
| Ambient Humidity | 35% ... 95% |
| Output Voltage Range | 24V ... 288V |
| Output Voltage Power | 1000VA (Max) |
| Voltage Resolution | 0.01% |
| Voltage Stability | 0.02%/120s |
| Load Change Rate | 0.01% |
| Voltage Distortion | ≤0.3% (Full linear load range) |
| Output Current Range | 1mA ... 120A (Up to 230A Max) |
| Output Current Power | 2000VA (Max) |
| Current Resolution | 0.01% |
| Current Stability | 0.02%/120s |
| Load Change Rate | 0.01% |
| Current Distortion | ≤0.3% (Full linear load range) |
| Continuous Current | 100A |
| Phase Adjustment Range | 0° ... 360° |
| Phase Resolution | 0.01° |
| Frequency Adjustment Range | 45Hz ... 65Hz |
| Frequency Resolution | 0.01Hz |
| Power Output Stability | 0.02%/120s |
