| ブランド名: | GENY |
| モデル番号: | YCSS-103 |
| MOQ: | 1 |
| 価格: | negotiate rates |
| 支払条件: | T/T、L/C、D/P、T/T |
| 供給能力: | 10個/ 1ヶ月 |
| Parameter | Specification |
|---|---|
| Test Voltage (Phase-Neutral) | 3 × (24 V - 288 V) or customized |
| Voltage Output Power | 3 × 100 VA, 3 × 250 VA, 3 × 500 VA, 3 × 1000 VA |
| Resolution | Better than 0.01% of full-scale range |
| Setting Accuracy | Better than 0.05% of final range value |
| Stability | Better than 0.005%/h (integration time: 150 s) |
| Load Regulation (0 to Max Load) | < 0.01% |
| Distortion Factor | < 0.3% (linear resistive load) |
| Harmonics | 2nd - 21st, freely programmable |
| Parameter | Specification |
|---|---|
| Test Current Range | 3 × (1 mA - 100 A) |
| Current Output Power | 3 × 150 VA, 3 × 350 VA, 3 × 750 VA, 3 × 1500 VA |
| Resolution | Better than 0.01% of full-scale range |
| Setting Accuracy | Better than 0.05% of final range value |
| Stability | Better than 0.005%/h (integration time: 150 s) |
| Load Regulation (0 to Max Load) | < 0.01% |
| Distortion Factor | < 0.3% (linear resistive load) |
| Harmonics | 2nd - 21st, freely programmable |
